Tektronix P6248 Differential Probe: Precision Measurement for High-Speed Signals

Features and Specifications: Tektronix P6248 Differential Probe, TekProbe Connect, 1.5 GHz, 1X/10X, 1 pF, 60 dB, P624x Series

Product Overview:

The Tektronix P6248 Differential Probe is a high-performance probe designed for precise and accurate differential measurements in high-speed electronic circuits. With its wide bandwidth of 1.5 GHz and low input capacitance of 1 pF, it provides exceptional signal fidelity and minimizes circuit loading.

Features:

Bandwidth: 1.5 GHz
Input Impedance: 1 MΩ // 1 pF
Attenuation: 1X/10X
Common Mode Rejection Ratio (CMRR): 60 dB
Differential Input Range: ±10 V
Probe Tip Spacing: 1.5 mm
TekProbe Connect Interface for easy connection and probe power
AutoProbe Interface for automatic probe setup and compensation

Specifications:

Bandwidth: 1.5 GHz (-3 dB)
Rise Time: 233 ps
Input Impedance: 1 MΩ // 1 pF
Attenuation: 1X/10X
CMRR: 60 dB (DC to 1 GHz)
Differential Input Range: ±10 V
Probe Tip Spacing: 1.5 mm
Probe Length: 1.2 m (4 ft)
Weight: 120 g (4.2 oz)

P6248 Differential Probe
Ground Lead
Probe Tip Accessories
User Manual

High-fidelity measurements: 1.5 GHz bandwidth and low input capacitance ensure accurate signal capture.
Versatile attenuation: 1X/10X attenuation allows for measurements on a wide range of signal levels.
Excellent CMRR: 60 dB CMRR minimizes common mode noise and improves signal-to-noise ratio.
Easy connection: TekProbe Connect interface simplifies probe setup and provides probe power.
Automatic compensation: AutoProbe interface automatically compensates the probe for optimal performance.

Value to the Customer:

The Tektronix P6248 Differential Probe empowers engineers and technicians with a powerful tool for precise differential measurements in high-speed electronic circuits. Its exceptional performance, ease of use, and versatility make it an invaluable asset for debugging, troubleshooting, and characterizing electronic systems.
