Kohler CH395 3031 Horizontal Engine

Kohler CH395 3031 Horizontal Engine
The Kohler CH395 3031 is a 366cc, single-cylinder, air-cooled, 4-stroke, horizontal-shaft engine designed for commercial and light industrial applications. With 11.7 horsepower, it is commonly used in equipment such as lawn mowers, small generators, and pressure washers.

BRAND
Kohler

MODEL NUMBER
CH395-3031

WARRANTY
3 Year Consumer & Commercial

SHIPPING WEIGHT
84

DISPLACEMENT
277cc

STARTER TYPE
Electric

CRANKSHAFT ORIENTATION
Horizontal

CRANKSHAFT TYPE
Straight

FUEL SYSTEM
Gasoline

GEAR REDUCTION
No

CRANKSHAFT DIMENSIONS
1″ x 3.49″

CRANKSHAFT DIAMETER
1″

CRANKSHAFT LENGTH
3.49″

CRANKSHAFT END TAPPED SIZE
7/16 – 20

CRANKSHAFT KEYWAY WIDTH
1/4″

CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE)
Counterclockwise

CYLINDERS
1

CYLINDER BORE TYPE
Cast Iron

AIR CLEANER TYPE
Quad-Clean 4-Stage All-Season Heavy Duty Cyclonic

FUEL PUMP
No

OIL COOLER
No

OIL CAPACITY
35

LOW OIL ALERT
No

LOW OIL SHUTDOWN
Yes

IGNITION SYSTEM
Electronic

CARBURETOR TYPE
Bowl

CHOKE CONTROL
Manual

BOLT CIRCLE
5,6-1/2

PTO HEIGHT
5 – 1/4
